Tech-Solutions reprecent Leading manufactures within offline filtration making use of highly developed and tested filter inserts that effectively removes particles, water and oxidation by-products (varnish) from most oil types used in the industry.
Our filtration systems offer the best cleanliness levels available on the market today.
The CJC™ Mobile Flushing Unit, MFU is used for filtration and flushing of gearboxes in rough environments, especially within the mining sector, such as truck shops, service sites etc.
The unit is constructed to handle high viscous gear oils even at very low temperatures. It is equipped with wheels for high mobility, integrated tank, heaters and several other unique features to handle this challenging application.
To optimise the filtration effect, the CJC™ MFU automatically adjusts the flow through the filters based on oil temperature and viscosity, and a built in CJC™ Oil Contamination Monitor, OCM makes it possible to monitor the oil cleanliness level during the entire filtration and flushing process.
CJC™ Filter Inserts have outstanding oil-filtration capability with dirt and water-holding capacities of up to 4 litres of dirt per insert.
All CJC™ Filter Inserts have an oil filtration degree of 3 µm (micron) absolute. This means that 98.7% of all solid particles larger than 3 µm and approximately 50% of all particles larger than 0.8 µm are retained in one pass.
CJC™ Filter Inserts are produced from unbleached cotton and/or semi-chemical cellulose. A Inserts are made from semi-chemical cellulose, and B Inserts are made from either cotton cellulose or a mix of cotton cellulose and semi-chemical cellulose.
Protect valuable investments!
Reduce operational cost!
Improve uptime!
Increase effective lifetime of your equipment!
Increase profit on operations!
Investment payback time typically less than 12 months – depending on application and size and importance of equipment
CJC™ Filter Separators are off-line oil filtration systems / oil separators, combining fine filtration with water separation all in one unit, with an integrated circulating pump.
They are designed for use in applications containing hydraulic oil, diesel fuel, lubrication oil, etc., in which water ingress is a constant or recurrent problem.
CJC™ Filter Separators remove water by coalescence and at the same time minimize oil contamination levels of particles and oil degradation products (oxidation resin/sludge, varnish).
The CJC™ depth filters have a filtration degree of 3 microns absolute and a very large dirt-holding capacity.
This, combined with efficient and continuous water removal from the oil, provides numerous benefits including reduced maintenance, increased productivity, and maximum lifetime of system components, in-line filters and oil.
The modular Filter Separators are built and sized to specific customer requirements - whether the oil volume is 2 litres or 200,000 litres.
CJC™ Filter Separators ensure trouble-free operation of marine hydraulics, marine diesel fuel systems, steam turbine lube systems and water-cooled hydraulic industry equipment.
diesel oils • diesel fuels • engine lube oils • gas oils • gear oils • heat transfer oils • honing oils • hydraulic oils • lube oils • lubricating oils • quenching oils • rolling oils • synthetic gear oils • turbine lube oils • water glycols
